Dettagli:
|
Tensione nominale: | 380 V | Corrente nominale: | 720A |
---|---|---|---|
Velocità: | 1500rpm/1800rpm | Frequenza: | 50 Hz/60 Hz |
Sistema di avvio: | 24V di avvio elettrico a corrente continua, 12V di avvio elettrico a corrente continua | Peso: | 4750X1450X2415MM/2450KGS |
Marca dell'alternatore: | Stamford | Modello alternatore: | S5L1D-C4 |
Uscita dell'alternatore: | 500KVA/400KW | Tipo: | Silenzioso / insonorizzato |
Controller/modulo di controllo: | DSE 6020 in acque profonde | Potere primario: | 500KVA /400KW |
Poweer in attesa: | 550KVA/440KW | Potenza massima del motore: | 451 kW (605 CV) |
Potenza in standby del motore: | 495 kW (664 CV) | Garanzia: | 12 mesi/1000 ore |
Generator Set Specifications | ||
Genset Model | KGC30S | |
Prime Power | 24KW | |
Engine Brand | With Cummins /Perkins/Deutz/Weichai/Yuchai/Doosan Etc. | |
Type | 4 Stoke, Water Cooled. | |
Alternator Brand | With Stamford/Leroy Somer/Marathon/Meccalt/Kingway Etc. | |
Type | Brushless | |
Connection | Single/Three Phase, 4 Wires | |
Control Panel Brand | Deepsea/Smartgen etc. | |
Type | Auto PLC Controller | |
Voltage | 230V/400V, 110V/220V, As Client's Requirement. | |
Frequency | 50HZ/60HZ | |
Type | Open/Silent/Trailer/Container | |
Applications | Home, Industry, Hotel, Hospital, Main Grid.Etc. | |
Delivery Method | By Sea, By Train. | |
Warranty | 12 Months/1000 Working Hours |
